AV – 250VAC
Product Details
The AV series is a wide range of pushbutton switches that offers the same robustness and aesthetics youÕve come to expect from APEM. Tested and qualified for impact resistance and sealing - IP and IK levels- these switches withstand all types of adversity
Product Information
£0.00
(£0.00 ex. VAT)
| Function: | 1.5 Nm min. - 4 Nm max. applied to nut |
| Tf Range: | ¯ 16 : 1 (.039) to 6 mm (.236) max.¯ 19 and ¯ 22 : 1 (.039) to 9 mm (.354) max. |
| Features 1: | Low level or mechanical life : 200-000 cycles |
| Features 2: | Hand soldering : 300 ¡C- 4 sec. max. |
| Features 3: | Bushing diameter 16- 19 or 22 mm |
| Features 4: | Latching action |
| Features 5: | Flat or curved actuator Actuator and bushing: nickel plated or stainless steel |
| Features 6: | Optionally sealed to IP65 |
